Ambitious manufacturing businesses that want to boost their R&D could turn to additive manufacturing. In this article, we’ll explore the different types of additive manufacturing, the benefits and weaknesses, as well as some industries that could benefit from additive manufacturing.

What is additive manufacturing?

Additive manufacturing (AM) is the process of adding substances to manufacture or create an object. While many believe that AM is a relatively new technology it has been around since the late 1980s. Additive manufacturing takes a transformative approach to assembly and industrial fabrication. AM uses computer-aided-design (CAD) software to guide digital hardware that accurately produces detailed geometric shapes. Through the meticulous deposit of layer upon layer of material, AM enables the creation of lighter, stronger parts and systems that bring digital flexibility and efficiency to manufacturing operations.

3d printing 3D printing supports low-volume, specialised products

7 categories of additive manufacturing

Commonly known as 3D printing and rapid prototyping, the terms refer to two of the independent processes that are subsets of additive manufacturing. There are seven different categories of additive manufacturing, these are:

1. Binder jetting

Also referred to as 3D printing or powder bed and inkjet. Binder jetting uses liquid materials printed onto thin layers of powder. Building layer by layer and, effectively glueing the particles together. Metals, foundry sand, and ceramics in the granular form are commonly used in binder jetting. Used in a variety of applications, such as the construction of large sand-casting moulds and the fabrication of low-cost 3D printed metal parts.

2. Directed energy deposition

Directed energy deposition uses thermal energy to fuse metal and metal-based materials by melting the material as it is deposited. Also referred to as laser metal deposition, plasma arc melting and direct metal deposition, it is used for low volume part fabrication, rapid prototyping, and repair.

3. Material extrusion

Otherwise referred to as fused layer modelling or fused filament fabrication, material extrusion uses continuous filament of polymer or composite material to construct 3D parts. The material is pushed through an extruding nozzle, where it is heated and then deposited, layer by layer, onto the build platform.

4. Material jetting

In material jetting, droplets of material are selectively deposited, continuously, or on-demand, onto the build platform. The deposit is then cured by a heat source or ultraviolet light to form a 3D object. Material jetting is also known as direct ink writing and multi-jet modelling and uses a similar process to that of a two-dimensional ink jet printer. Material used in this method include polymers, waxes, composites, and biological materials.

5. Powder bed fusion

The powder bed or multi-jet fusion process includes the various printing techniques of selective laser sintering and melting, direct metal laser sintering, electron beam melting, and selective heat sintering. High-power thermal energy via a laser or electron beam, is used to melt and selectively fuse material powder together.

6. Sheet lamination

Sheet lamination is an additive manufacturing process that bonds together thin sheets of material. Also referred to as selective deposition lamination and laminated object manufacture, sheets are usually feed via a system of rollers. They are then bonded together, layer-by-layer, to form a single sheet.

7. Vat photo polymerisation

The earliest method of 3D printing, vat photo polymerisation creates 3D objects using special resins called photopolymers. The liquid photopolymer is selectively cured by targeted, ultraviolet, light-activated polymerisation.

additive manufacturing Explore new manufacturing options in a cost-effective way

12 benefits of additive manufacturing

The benefits of additive manufacturing are numerous, each of these individual benefits of additive manufacturing also have in common a certain degree of waste reduction and/or energy savings. The following a just some of the many benefits of additive manufacturing:

1. Accelerated prototyping

AM expedites product development by enabling the creation of many varying prototypes that can be produced faster and cheaper in comparison to lengthy traditional methods. Several prototypes can be printed before committing to a production run, leaving less room for error in the whole process. In AM, any changes to the original specification are made digitally, reducing the modification costs to achieve the desired result. Traditional design modifications are generally more expensive to undertake.

2. Customisation

AM manufacturing offers design innovation and creative freedom without the cost and time constraints of traditional manufacturing. The ability to easily alter original specifications means that AM offers greater opportunity for businesses to provide customised designs to their clients. With the ease to digitally adjust design, product customisation becomes a simple proposition. Short production runs are then easily tailored to specific needs.

3. Energy savings

In conventional manufacturing, machinery and equipment often require auxiliary tools that have greater energy needs. AM uses fewer resources, having less need for ancillary equipment, and thereby reducing manufacturing waste material. AM reduces the number of raw materials needed to manufacture a product. As such, there is lower energy consumption associated with raw material extraction, and AM has fewer energy needs overall.

4. Environment benefits

The environmental benefits of additive manufacturing are an advantage to businesses seeking to improve manufacturing sustainability. AM offers many positive environmental benefits in comparison to traditional manufacturing. The most notable of which are waste reduction and energy savings. The processes of additive manufacturing, compared to traditional manufacturing, are more efficient and significantly reduce the environmental impact of waste products. AM offers greater material efficiency because it only uses what is needed to create a product.

5. Inventory stock reduction

AM can reduce inventory, eliminating the need to hold surplus inventory stock and associated carrying costs. With additive manufacturing, components are printed on demand, meaning there is no over-production, no unsold finished goods, and a reduction in inventory stock.

  • Read more: Manufacturers, Clear Out Your Excess Inventory!
  • 6. Legacy parts

    AM has gifted companies the ability to recreate impossible-to-find, no longer manufactured, legacy parts. For example, the restoration of classic cars has greatly benefited from additive manufacturing technology. Where legacy parts were once difficult and expensive to find, they can now be produced through the scanning and X-ray analysis of original material and parts. In combination with the use of CAD software, this process facilitates fast and easy reverse engineering to create legacy parts.

    7. Manufacturing and assembly

    A significant benefit of additive manufacturing is the ability to combine existing multi-part assemblies into a single part. Instead of creating individual parts and assembling them at a later point, additive manufacturing can combine manufacturing and assembly into a single process. Effectively consolidating manufacture and assembly into one.

    8. Material waste reduction

    In conventional manufacturing processes, material is typically removed from a larger piece of work; think timber milling or cutting shapes from sheets of steel. In contrast AM starts from scratch, adding material to create a component or part. By using only the substance necessary to create that part, AM ensures minimal waste. AM also reduces the need for tooling, therefore limiting the amount of material needed to produce components.

    9. Part flexibility

    Additive manufacturing is appealing to companies that need to create unusual or complex components that are difficult to manufacture using traditional processes. AM enables the design and creation of nearly any geometric form, ones that reduce the weight of an object while still maintaining stability. Part flexibility is another major waste reduction aspect of AM. The ability to develop products on-demand, inherently reduces inventory and other waste.

    10. Part reliability

    Small components and those with intricate parts, or small moving pieces typically require strict manufacturing tolerances and very controlled assembly processes. Additive manufacturing methods help to reduce the number of component defects and improve part reliability. Additive manufacturing technology allows manufacturers to print entire components with precise tolerances. Thereby, improving part reliability and product quality.

    11. Production flexibility

    A key benefit of additive manufacturing is the ability of producers to quickly switch between different products. Allowing a more streamlined supply chain and economical production batches, minus costly and/or time-consuming setup. This inherent made-to-order technology with the flexibility to create small batch orders, means producers end up with fewer unsold products and less inventory waste.

    12. Supply chain improvements

    The benefits of additive manufacturing on supply chains takes many forms. It reduces material waste, simplifies production processes, and the on-demand production offered by additive manufacturing improves supply chain flexibility because the finished product can be manufactured in proximity to the end-user. AM improves process flexibility that enables supply chains to quickly react to demand, lowers supply chain risk by providing a contingency plan and helps to reduce supply-related costs.

    CAD software Is additive manufacturing right for your business?

    5 disadvantages of additive manufacturing

    1. Cost of entry

    With additive manufacturing, the cost of entry is still prohibitive to many organisations and, in particular, smaller businesses. The capital costs to purchase necessary equipment can be substantial and many manufacturers have already invested significant capital into the plant and equipment for their traditional operations. Making the switch is not necessarily an easy proposition and certainly not an inexpensive one.

    2. Production costs

    Production costs are high. Materials for AM are frequently required in the form of exceptionally fine or small particles that can considerably increase the raw material cost of a project. Additionally, the inferior surface quality often associated with AM means there is an added cost to undertake any surface finishes and the post-processing required to meet quality specifications and standards.

    3. Additional materials

    Currently there is a limit to the types of materials that can be processed within AM specifications and these are typically pre-alloy materials in a base powder. The mechanical properties of a finished product are entirely dependent upon the characteristics of the powder used in the process. All the materials and traits required in an AM component have to be included early in the mix. It is, therefore, impossible to successfully introduce additional materials and properties later in the process.

    4. It’s slow

    As mentioned, additive manufacturing technology has been around since the eighties, yet even in 2021, AM is still considered a niche process. That is largely because AM still has slow build rates and doesn’t provide an efficient way to scale operations to produce a high volume of parts. Depending on the final product sought, additive manufacturing may take up to 3 hours to produce a shape that a traditional process could create in seconds. It is virtually impossible to realise economies of scale.

    5. Post-processing

    A certain level of post-processing is required in additive manufacturing because surface finishes and dimensional accuracy can be of a lower quality compared to other manufacturing methods. The layering and multiple interfaces of additive manufacturing can cause defects in the product, whereby post-processing is needed to rectify any quality issues.

    5 applications of additive manufacturing

    Additive manufacturing has been advancing in technology since the late 1980s and has experienced widespread use in the past decade. While the applications of additive manufacturing will continue to grow, the benefits of additive manufacturing have already vastly transformed the following five industries:

    Aerospace

    With some of the most demanding industry standards in terms of performance, the aerospace industry was one of the first to adopt additive manufacturing. The commercial and military aerospace domain needs flight-worthy components that are made from high-performance materials.

    Common AM applications in the aerospace space, include environmental control system ducting, custom cosmetic aircraft interior components, rocket engines components and combustor liners. Additive manufacturing helps deliver complex, consolidated parts with the enhanced strength that is a requisite in the industry. With consolidated designs that require less material and overall weight reduction, which is a crucial factor for the aerospace industry.

    Consumer products

    Marketing teams, designers, and graphic artists function to form ideas and deliver products to market as quickly as possible while adapting to fluctuating trends and consumer demand. Part of this process is spent simulating the look and feel of the final product.

    AM has proven beneficial to the product development of many consumer goods such as sporting goods and consumer electronics. Quickly delivering detailed iterations early in the product development life cycle, with fine details, functionality, and realistic aesthetics. As AM technology advances in speed and build volume, it is likely that more consumer products will look to additive manufacturing for larger volume demands.

    Energy

    Additive manufacturing’s innovation in producing efficient, on-demand, lightweight components has driven success in the energy sector. Centring on AM’s capability to quickly create tailored components and environmentally friendly materials that can withstand extreme conditions.

    Key AM applications that have developed in the gas, oil and energy industries include various control-valve components, pressure gauge pieces, turbine nozzles, rotors, flow meter parts, and pump manifolds. With the capability to develop corrosion resistant metal materials AM has the potential to create customised parts for use under-water or other harsh environments, associated with the industry.

    Medical

    The rapidly innovating medical industry utilises AM solutions to deliver breakthroughs in functional prototypes, surgical grade components, and true to life anatomical models. AM in the medical field is producing advancements in the areas of orthopaedic implant and dental devices, as well as tools and instrumentation such as seamless medical carts, anatomical models, custom saw and drill guides, and custom surgical tools.

    Material development in the medical industry is critical with the certified biocompatible materials potentially revolutionising areas of customised implants, and the life-saving devices and pre-surgical tools to increase patient results.

    Transportation

    The transportation industry requires parts that withstand extreme speeds and heat, while still being lightweight enough to avoid preventable drag. The benefit of additive manufacturing’s ability to develop lightweight components has led to more efficient vehicles.

    Many of the AM applications transforming the transportation industry include complex ductwork that is unable to be fabricated using conventional methods, resilient prototypes, custom interior features, grilles, and large panelling.

    AM technology will continue to evolve product design and on-demand manufacturing. As design software becomes more integrated and easier to use, the benefits of additive manufacturing will grow to significantly influence an increasing number of industries.
